Air Cooled Water Chiller Machine For Plastic Pipe / Sheet / Board
Quick Detail:
.Temperature range is 3-50 C
2.Compressor over-current protection, flow alarm, over temperature
alarm
3.checked manufacturer
Description:
1. The machines uses brand compressor imported from Europe,
American and Japan; can guarantee reliable running, high
efficiency, low noise, power saving and long using life;
2. Microcomputer intelligent temperature controller, high precision
digital display, the water temperature control accuracy can reach
±1°C. Temperature range is 3-50°C, can set at any temperature
within this range;
3. Open type stainless steel thick incubator with built-in
automatic water adding and automatic temperature control;
4. Water chilling unit condenser is casing pipe type, uses inner
grooved copper tube, reasonable design assures high heat exchange
efficiency;
5. Air cooling unit radiator is composed of tubes; using mechanical
tube technology and heat exchanger production line, to guarantee
high efficiency;
6. Electro-static plastic sprayed outer shell, Europeanized design,
elegant outlook; the outer panel is of easy dismantlement, to
guarantee convenient usage and maintenance.
Applications:
The air cooling-water machine is widely used in many industries,
including chemical, paper making
industry, electronics, pharmacy, food processing industry, aluminum
profiles, aluminum alloys, tempering
glass, coated glass industry, laser technology, laser technology,
jewelry processing, leather processing,
cultivation industry, etc.
Specifications:
Model | CDW-5HP |
Voltage | AC3N-380V |
Frequency | 50HZ |
Refrigerating capacity | 12500W |
Compressor power | 4.02KW |
CDW-DH |
Max. Flow | 36L/min |
Chilled water outlet | 1(1'') |
Water tank capacity | 50L |
Water pump motor | 0.5 HP |
Net weight | 195kg |
Safety protection | Compressor over-current protection, flow alarm, over temperature
alarm |
Refrigerant | R22, R410 |
Flow controller | Capillary tube, expansion valve |
Outer dimension (mm) | 1106x680x980 |
Competitive Advantage:
We are an expert manufacturer of various cooling machines: air
cooling machine, injection mold cooling
machine, bottle blow cooling machine, laser cooling machine, open
type cooling machine, screw type
cooling machine, etc.
