Low Temperature Carrier Air Cooled Water Chillers with Dual
Compressor
Quick Detail:
1. High/Low pressure protection for the compressor and overheating
protection inside the machine
2. Low water level alarm and low water temperature alarm
3. Certification:CE & ISO
4. Compressor type: Totally closed vortex type or piston type
5. Refrigerating capacity: 4872Kcal/h(50HZ)
6. Warranty:1 year
Description:
- High/low pressure protection for the compressor and overheating
protection inside the machine
- Low water level alarm and low water temperature alarm
- Imported compressor from Europe, US and Japan
- Refrigerating system welded with oxygen free method, to reduce
oxides and ensure the smooth surface
- Throttle components from Danfoss (Denmark) and Alco (US)
- SUS304 stainless steel water tank, to avoid corrosion or water leak
- Stainless plate, coil, shell and tube or fin type efficient heat
exchanger
- RS485 communication function, to realize automatic
management(optional)
- Electrical devices supplied from OMRON, FUJI, TE, LG, MOELLER and
SCHNEIDER
- Control mode: imported micro-computer or PLC(optional)
- Perfect safety protection, failure display, and not requiring
professional personnel for maintenance
- Highly efficient evaporator and condenser, to save over 30% energy
- 2 compressor heads for over AC-08, for individual or joint
operation
Specifications:
ITEM | UNIT | AC-02A |
Cooling capacity | KW50HZ | 5.67 |
| Kcal/h 50HZ | 4872 |
Total input | KW | 2.6 |
Maximum Running Current | A | 15.8 |
Power supply |
| 1N-220V 50HZ |
Refrigerant | Name | R22 |
| Charge | Kg | 1.8 |
| Control Type | Capillary Tube |
Compressor | Type |
| Hermetic Rotary |
| Power | Kw | 1.5 |
Air Flow | M3/h | 2000 |
Chilled water | Flow | M3/h | 0.97 |
| Tank | M3 | 0.038 |
| In/Out Pipe Size | G3/4” |
water Pump | Power | Kw | 0.375 |
| Pressure | Kpa | 250 |
Size(L×W×H) | mm | 820×460×1170 |
Weight | Kg | 120 |
Competitive Advantage:
- Our core competitiveness:advance technology,the pioneer of TCU
industry, Convenient and efficient nationwide service network
- Excellent R&D team
- Customization thick copper pipe 1.0-1.2
- Our core concept:Innovation, high-quality, integrity, service,
focus
- High density heat insulation cotton and aluminum foil
- Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST
- The thickness of our machine rack is 1.2mm
- We have the production certification organic heat transfer material
heater
Applications:
Aluminium Alloy: Car accessories
Magnesium alloy: Communication device, navigation
Hot Rolling Machine: Calender Rolls, Wood Presses, Laminating
Presses,Molding Presses, Rubber Presses, Jacketed Vessels,
Reactors, Heat Exchangers, Mixers, Printing Machines, Asphalt,
Vulcanizing Presses.
Die casting,plastic Injection molding, light guide plates,
connectors, Chemical engineering, Shoe materials, Pringting and
dyeing, Drying and banburying.
Nowadays, Aode Machinery Co.,ltd continue to uphold the purpose of
international standards designs and high quality products, applying
ourselves to providing high standard products and whole-journey
nanny service. Our products are widely applied in plastic injection
molding, light guide plates, connectors, chemical engineering,
compression casting, reaction kettles, rubber tires, calendaring,
shoe materials, printing and dyeing, drying and banburying and tec.
And widely sold to Japan, America, Italy, Brazil, Southeast Asia,
Africa and etc. The brand recognition from the market is sufficient
to prove that our temp. control system can replace the imported
similar products. Belows are our honor clients.
